Features:

Microphone Inputs:    Female XLR Pin 2 Hot
Input Impedance:    3kΩ balanced
Phantom Power:    +48 Volts
Maximum gain:    +58 dB
E.I.N. (at max gain):    -125 dBu @ 58dB gain typical (150ohm source) -129 dBu @ 58dB gain typical A-weighted (150Ω source)
Maximum Input Level:    +21 dBu at minimum gain
Frequency Response:    +0/-1 dB, 20Hz – 20kHz
THD+N:    <0.006%, 20Hz – 20kHz (mic input to main output) 0 dBu input level, Input knobs at 11 o’clock
<0.003%, 1kHz, +5 dBu input level, Input knobs at minimum, Output knob at max
Line Inputs:    1/4″ TRS balanced or unbalanced
Input Impedance:    20kohm balanced, 13kohm unbalanced
Maximum Input Level:    +32 dBu
Frequency Response:    +0/-1.5 dB, 20Hz – 20kHz (reference 1kHz)
THD+N:    <0.004%, 20Hz – 20kHz (line input to main output) 0 dBu input level, Input knob at 12 o’clock, Output knob at max
Instrument Input:    1/4″ TS unbalanced
Input Impedance:    1MΩ
Maximum Input Level:    +13 dBu
Frequency Response:    +0/-2 dB, 20Hz – 20kHz (instrument input to main output)
THD+N:    <0.004%, 20Hz – 20kHz, 0 dBu input level, Input knob at 10 o’clock, Output knob at max
Line Outputs:    1/4″ TRS balanced or unbalanced
Level:    >+18 dBu maximum
Impedance:    32ohm Balanced, 16Ω Unbalanced
Headphone Output:    1/4″ stereo jack 350mW per channel at 50ohm
MIDI Interface:    5 pin DIN connectors for MIDI in and MIDI out (5 volt signal)
Sample Rate:    44.1, 48, 88.2, or 96 kHz (determined by computer application)
Dynamic Range:    A/D (24 Bit) 108 dB typical, A-weighted, 20Hz – 20kHz
(44.1 kHz sample rate)
D/A (24 Bit) 110 dB typical, A-weighted, 20Hz – 20kHz
A/D/A (24 Bit) 102 dB typical, A-weighted, 20Hz – 20kHz
Power Requirements:    12W 9VAC
Power adaptors available for:
US and Canada: 120 VAC, 60 Hz Adapter: PS0913B – 120
Japan: 100 VAC, 50/60 Hz Adapter: PS0913B – 100
Europe: 230 VAC, 50 Hz Adapter: PS0913B – 230
UK: 240 VAC, 50 Hz Adapter: PS0913B – 240
Australia: 240 VAC, 50 Hz Adapter: PS0913B – 240-AU
Lexicon engineers are constantly working to improve the quality of our products. Specifications are therefore subject to change without notice.
