Features:

• 8×4 – 24-bit/96kHz analog I/O (1/4″TS) or 2×4 24-bit/192kHz analog I/O
• 8×8 ADAT lightpipe I/O with S/MUX support for 4-channel 96kHz operation
• Digital S/PDIF (optical/coaxial) I/O with 2-channel PCM
• Digital out supports pass-through of AC-3/DTS surround-encoded content
• Dual mic/instrument preamps (Neutrik XLR/1/4″ TS) with input level controls, 20dB pad, phantom power, and signal LEDs
• Dual stereo headphone outputs with individual level controls (1/4″ TRS)
• Flexible software-controlled mixing of hardware and software I/O
• Aux sends on all channels; aux out assign allows dedicated earphone mixes and sends to external effects
• User-assignable front-panel level control (output, input, software return, aux send)
• Near zero-latency hardware direct monitoring
• Low-latency ASIO software direct monitoring
• Momentary switch for A/B cueing 2 software-assignable headphone sources or ASIO monitoring on/off
• 1×1 – 16-channel MIDI I/O
• Word clock I/O
• Power on/off with LED
• Powered via FireWire bus or included DC power adapter
• 2 convenient high-bandwidth FireWire ports
• Compatible with Pro Tools M-Powered 8
