Features:

• 8 analog inputs/outputs with 24-bit, 96kHz converters on balanced/unbalanced 1/4″ TRS jacks.
• Three banks of ADAT optical provide 24 channels of ADAT optical input/output at 44.1/48kHz
• 12 channels at 88.2/96kHz.
• Three banks of Tascam TDIF provide 24 channels of TDIF (Tascam digital) input/output
• 12 channels at 88.2/96kHz.
• Stereo S/PDIF in/out (with an extra stereo out).
• Provides stand-alone format conversion
• Transfer any format to any other, up to 24 channels at a time.
• 8 analog inputs/outputs with 24-bit, 96kHz converters on balanced/unbalanced 1/4″ TRS connectors
• 108dB S/N ratio (A-weighted)
• 24 channels of ADAT optical input/output
• 24 channels of TDIF (Tascam digital) input/output
• 2 channels of S/PDIF in and 4 channels out
• 16, 20 and 24-bit recording at 44.1, 48, 88.2 and 96kHz kHz
• ADAT sync input on PCI-424 card
• Word clock in and out
• Includes cross-platform PCIX-424 or PCIe-424 card
• Chassis dimensions, excluding rack ears and front and back panel knobs and connectors: 19 x 7 x 1.75 inches (48.26 x 17.78 x 4.45 cm). Knobs and connectors extend up to 0.5 inch (1.27 cm) from front and back panels, adding 1 inch (2.54 cm) to depth. With rack ears attached, fits standard 19 inch (48.26 cm) rack at 1U high.
