Features:

• Receiver Type: Synthesized PLL
• Number of Channels: 1112 possible channels Programmable in 25 k Hz steps.
• Modulation: +/- 40 kHz
• Diversity: Digital Posi-Phase True Diversity.
• RF Sensitivity: < 1.0 mV for 12 dB SINAD
• Image Rejection: > 60dB
• Squelch: Tone Code plus Amplitude
• Ultimate Quieting: > 100dB
• FCC Certification: Approved under Part 15
• Power Requirements: 12 VAC, 300mA max
• Frequency Response: 50 Hz – 15.000 Hz +/- 2dB
