Features:

• 24 additional Mix-B input channels, all with individual 2-band EQ, Level, Pan and Mute
• Dedicated 4-band EQ with 2 semi-parametric Mid bands offering an extremely wide-swept range from 50 Hz to 20 kHz
• Up to 6 Aux send busses, all switchable pre/post fader
• 6 stereo Aux returns with multiple routing options
• 8 subgroups simultaneously feed 16 multitrack outputs
• Built-in meterbridge with meters for each channel, subgroup and Main mix, monitoring either the channel or Tape return signal
• +15 dB gain available on all Aux sends and returns
• Highest-quality, discrete-balanced Mic preamps with -20 dB pad, Low-cut and 48 V phantom power
• Balanced Tape inputs/outputs, switchable for -10 dBV or +4 dBu operation
• Channel, Group and Main mix insert points
• 100 mm high-precision logarithmic, tapered faders with big console performance
• Separate solo-in-place and PFL busses available
• 2-track tape monitoring with multiple routing options
• 2 separate headphone mixes and Talkback facility with built-in microphone
• State-of-the-art op-amps for crystal clear audio performance
• BNC connectors for 12 V gooseneck lights
• Expander port providing universal 1/4” link facilities to any other console
• 400-Watt, external 19” power supply with superior transient response
• High-quality components and exceptionally rugged construction ensure long life
• Designed and engineered in Germany
