Features:

• Formats: 24 or 32 inputs (each with 2 dual stereo inputs, giving 52 or 68 inputs to the mix)
• 8 audio groups
• Twin fader, dual path input (100mm ‘A’ path fader, 60mm ‘B’ path fader)
• 2 patchable valve (tube) preamps
• The main fader path is always used for monitoring, eliminating the need for fader swapping
• 6 auxiliary sends, accessible from A or B path
• 4 band EQ with separate controls for sweep and cut/boost on mid bands. Rotary ‘Q’ controls, EQ in/out switching and routing via A or B path
• MIDI mute automation with scenes and groups is provided as standard, together with MMC, allowing control of tape machine functions from the console
• Solo-in-place and PFL
• 2 studio playback feeds
• Control room and alternative speaker feeds
• Peak led metering on channels and 12 segment bargraph meters on groups and LR. A bargraph meterpod was offered as an option
