Features:

• Self-contained digital console; may be used without external hardware
• 24 mic/line inputs with MIDAS mic preamps
• 48 simultaneous input processing channels
• 24 analog outputs (including 2 stereo local monitor outputs)
• 2 AES3 inputs, 3 AES3 outputs
• 27 sample-synchronous, phase-coherent mix buses
• Up to 12 multi-channel FX engines
• 4-band parametric EQ on each input channel
• Up to 28 instances of the KLARK TEKNIK DN370 31-band Graphic EQ
• Stereo, SIS (LCR panning) Quad (4-channel), LCRS (Left, Centre Right Surround), and 5.1 panning
• Full-color 15″ daylight-viewable display screen
• 8 VCA (Variable Control Association) groups, 6 POPulation groups
• MIDI in/out/thru, ethernet, removable power supply
• 96kHz 40-bit floating-point processing throughout
• Showfiles are compatible with all MIDAS digital consoles
• Expandable with optional external hardware I/O units (max capacity: 100 inputs x 102 outputs)
